Oxy-Acetylene Cutting Table DXF & Blueprints
Oxy-Acetylene Cutting Table DXF & Blueprints - Ready to Cut
Bring professional-grade craftsmanship to your workshop with this Oxy-Acetylene Cutting Table DIY Project, designed for CNC plasma cutting enthusiasts! Perfect for welders of all levels, this project equips you with everything you need to cut, assemble, and customize a durable and functional cutting table from scratch. Whether you're an experienced fabricator or just starting out, this table will be a valuable addition to your workspace.
Table Dimensions: Inside measurements are 2' x 4'.
What’s Included:
- DXF Files – CNC-ready files optimized for plasma or laser cutting.
- Scaled Blueprints – Detailed fabrication drawings with dimensions and assembly layout.
- Materials List – Suggested steel thicknesses and material recommendations.
Key Features:
- Removable slats for easy replacement.
- Foot plates pre-designed to fit casters (link provided in the materials list).
- The funnel pieces contain a 1/8" gap in between for easy placement, yet close enough to easily weld.
- Decorative bottom shelf featuring an Oxy-Acetylene torch cutout design. The shelf is positioned low enough to fit a metal 5-gallon bucket for catching sparks and cut pieces.
All parts can be cut from a 4' x 8' x 1/8" sheet of mild steel (excluding square tubing). Ideal for anyone looking for a functional and attractive cutting table for their workshop!
This design is perfect for DIY welding projects, hobbyists, and welding and ag mechanics classes. It's a fantastic addition to any welding shop looking for a practical and customizable cutting table.
Why Choose This Package?
Save hours of design time and get straight to fabrication. Whether you're a professional welder, advanced DIYer, or welding instructor, this ready-to-cut package streamlines your project workflow. Just load the DXF onto your CNC plasma table, cut your parts, and assemble using the scaled blueprints.
Made in the USA.
This is a digital product only. No physical items will be shipped.
