Fire Pit Santa Maria Grill DXF & Blueprints

Fire Pit Santa Maria Grill DXF & Blueprints – Ready to Cut

Take your backyard cooking to the next level with this versatile Fire Pit Santa Maria Grill digital package! Designed for fabricators, DIYers, and welding students, this CNC plasma-cut-ready project combines the classic Santa Maria adjustable grate system with a built-in fire pit for authentic open-fire grilling.

Grate Dimensions: 32"

What’s Included:
DXF Files – CNC-ready files optimized for plasma or laser cutting from standard 4’ x 8’ x 3/16” steel sheets. (2 sheets required)
Scaled Blueprints – Clear, detailed, and scaled plans for precise fabrication.
Materials List – Comprehensive list including square tubing, bolts, and pipe.

Key Features:
Adjustable Grill Grate – Classic Santa Maria pawl and ratchet system for easy height control.
Integrated Fire Pit Design – Grill directly over wood or charcoal with a built-in octagonal pit structure.
Heavy-Duty Build – Engineered for long-term outdoor use and high-heat durability.

Why Choose This Package?
Save hours of design time with CNC-ready DXF files and professional blueprints. Perfect for experienced welders, hobbyists, welding students, or anyone seeking a hands-on, rewarding fabrication project. Whether you're building it for your backyard, as a gift, or to sell, this Fire Pit Santa Maria Grill is both functional and visually impressive.

This is a digital product only. No physical product will be shipped.

Proudly designed in the USA.
