Cabinet Smoker DXF & Blueprints

📦 Instant digital download • DXF + PDF files • Licensed for classroom/personal use, not for resale

Cabinet Smoker DXF & Blueprints – Ready to Cut

Elevate your outdoor cooking setup with this professional-grade Cabinet Smoker digital package. Designed specifically for CNC plasma cutting, this 6' tall, 24" x 48" smoker is engineered for precision, efficiency, and durability—ideal for DIY fabricators, welding students, and professional shops looking for a high-performance smoker build.

What’s Included:
DXF Files – CNC plasma-ready files, optimized for cutting from (4) 3/16” x 4’ x 8’ mild steel plates.
Scaled Blueprints – Highly detailed plans for accurate fabrication and assembly.
Materials List – Complete breakdown of required materials, including cut-to-size components.
Rendered Photos – Visual references to guide the fabrication process.

Key Features:
CNC Plasma Cut Components – All parts, including the hinges, vents, handle, and latch system, are precision-cut using a CNC plasma table for a perfect fit and seamless assembly.
Heavy-Duty Construction – Designed for durability and long-lasting performance.
Caster-Ready Plates – Allows for easy mobility (casters not included).

Why Choose This Package?
This ready-to-cut package saves time and eliminates guesswork, providing all the necessary files and plans for a seamless CNC plasma cutting and fabrication process. Whether you're an experienced welder, a fabrication shop owner, or a student working on a hands-on project, this smoker design enhances your metalworking skills while producing a professional-grade cooking unit.

Perfect for welding instructors, makerspaces, and DIY builders, this project is designed for efficiency and precision.

This is a digital product only. No physical items will be shipped.

Made in the USA.
