4" Rocket Stove DXF & Blueprints
4" Rocket Stove DXF & Blueprints – Ready to Cut
Take your outdoor cooking and fabrication projects to the next level with this 4" Rocket Stove Digital Package. Designed for fabricators, welders, DIYers, and ag mechanics students, this CNC-ready rocket stove is built for efficient fuel use, strong airflow, and durable performance. This project is primarily fabricated from a single 4' x 4' sheet of 3/16" hot rolled steel cut using a CNC plasma or laser cutter, making material planning straightforward and cost-effective. Ideal for camping, off-grid cooking, backyard use, and classroom fabrication projects.
Dimensions Include:
4" Rocket Stove
18" Chimney
12" Air Intake
What’s Included
DXF Files – CNC-ready files optimized for plasma or laser cutting.
SVG Files – Compatible format for a wide variety of cutting software.
Scaled Blueprints – Detailed drawings with measurements for accurate fabrication and assembly.
Materials List – Includes recommended steel thickness and material specifications.
Rendered Images – High-quality visuals showing the completed rocket stove design.
Key Features
- 18" chimney for improved draft and efficient heat output.
- 12" air intake designed for consistent airflow and clean combustion.
- Removable ash pan for easy cleanup and maintenance.
- Integrated carry handle for portability and transport.
- Adjustable damper to control airflow and burn rate.
- Removable top for versatile cooking options and easy replacement.
- Collapsible base for compact storage and easy transport.
- Ideal wood size is 10" long and 1–2" in diameter for optimal burn efficiency.
Why Choose This Package?
This digital package eliminates guesswork by providing CNC-ready files and clearly scaled blueprints. It is an excellent shop project that builds cutting, fit-up, and welding skills while producing a highly functional rocket stove. Well suited for welding programs, ag mechanics classes, small fabrication businesses, and DIY metalworkers.
This is a digital product only. No physical product will be shipped.
Proudly designed in the USA.
